PSA 14.7'' Hammer-forged, Mid-length, Light Profile Upper

Availability: In stock

As low as: $419.95

Price as configured: $0.00

Quick Overview




Barrel length 14.7"
Hammer Forged Barrel
Machine Gun Steel
5.56 Nato Chamber
1 in 7" twist
Double-thick Chrome-lined bore and chamber
Special lighter weight A2 profile
Mid-length gas system
M4 feedramps
Forged upper
T-marks
Full auto bolt carrier
Carpenter 158 Bolt
Optional pinned A2 flash hider

14.7'' CHF Midlength LW Classic

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

  • 14.7'' CHF Midlength LW MOE FDE
  • 14.7'' CHF Midlength LW MOE OD
  • 14.7'' CHF Midlength LW Classic
  • 14.7'' CHF Midlength LW MOE FG
  • 14.7'' CHF Midlength LW MOE BLK
  • 14.7'' CHF Midlength LW Barrel Profile
PSA 14.7'' HF Mid Lighter Weight Upper   +$419.95
A2 Flash Hider   +$0.00

* Required Fields

Price as configured: $0.00

Details

Barrel:  A proprietary blend of Hammer forged chrome molly vanadium made by FN that is referred to as "Machine Gun Steel" by virtue of its use in FN's M249 and M240 weapons.   The hammer forging process work hardens the steel, making it more durable.  In addition, the chrome process for the bore allows for a lining almost twice as thick as a standard M16 for enhanced durability.  Chambered in 5.56 NATO, with a 1/7 twist, M4 barrel extension, and a Mid-length gas system.   Lighter weight barrel has an A2 profile under the handguards and just enough material removed after the FSB.  Barrel is Mil-spec phosphate coated, High Pressure tested and Magnetic Particle inspected, and finished off with an F-marked front sight post with sling swivel, standard handguards and a the option of a pinned and welded A2 flash hider.  14.7" barrel allows for the A2 flash hider to bring the barrel to legal length.  This is not a pencil barrel.

Upper: Forged 7075-T6 A3 AR upper is made to MIL-SPECS and hard coat anodized black for durability. Featuring machined T marks, and a mil-spec finish. These uppers are made for us right here in the USA by a mil-spec manufacturer, and are marked with the Palmetto State Armory logo on the left side, up front, just below the rail.

Bolt: Bolt is made of Mil-spec shot-peened Carpenter 158 steel. Gas key is secured with grade 8 fasteners and staked per mil-spec. Bolt carrier is parkerized outside, chrome lined inside, and laser engraved with the Palmetto State Armory logo.

*Please allow up to 15 business days for your Complete Assembled Upper to ship from our facility.  Holiday and special lead times can be longer*

Shipping labels are created shortly after orders are placed.  Shipping labels update when the product leaves our facility and are en route to their destination. You will be emailed tracking information when the order leaves our facility, however if you receive one shortly after you place your order and it remains dormant, don’t be alarmed. Your tracking information will be updated when it leaves our facility and is still subject to the aforementioned lead time.  If your tracking number goes beyond the listed lead time please get in contact with us via email or phone and we will look into your issue.

Signature required on delivery.
