Federal XM193F 5.56mm 55gr FMJ

Availability: TEMPORARILY OUT OF STOCK

Quick Overview

• XM193 product is first run, first quality product manufactured at Lake City Army Ammunition Plant for Federal Cartridge and is made to Federal specifications typical for commercial ammunition.


• All XM193 product is the same regardless of the sku or part number. (ie. XM193C is the same as XM193F, XM193CBP and etc…) The only difference is the package configuration.


Below are the specifics of the XM193 loads.





Load No. - XM193


Velocity - 3165 fps


Ballistic Coefficient - 0.250

Federal XM193F 5.56mm 55gr FMJ

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Details

Features

  • CALIBER: 5.56 mm, manufactured at the Lake City Army Ammunition Plant (LCAAP)
  • CASE: Brass (Copper Alloy No. 260)
  • BULLET: 55 gr. FMJ Boat-Tail
  • PRIMER: M41 Operating Range: (-40 degrees to +125 degrees F)
  • PRIMER SEALANT: Water resistant lacquer
  • CASE MOUTH SEALANT: Yes
  • CASE KNURL: No
  • HEADSTAMP: Each loaded cartridge shall be headstamped with the manufacturer's symbol and year of manufacture
  • ACCURACY: 3-10round groups not to exceed 2.00" mean radius maximum average at 200 yards
  • INSTRUMENTAL VELOCITY: 3165 +/- 40 FPS (78 feet from muzzle) using a 5.56 test barrel, 20" long
  • ENERGY: 1223 Ft-Lbs. at 78’
  • CHAMBER PRESSURE: Piezotronic maximum average per 10 rounds - 55000 PSI in 5.56 test barrel (case mouth location)
  • BULLET PULL: Minimum individual 35 lbs.
  • PROPELLANT DETECTION: 100% mechanical and/or electrical detection of propellant levels within the cartridge
  • VISUAL INSPECTION: 100% visual inspection of finished cartridges prior to packaging
  • WARNING: For use in standard 5.56 mm chambers. Do not use in non-standard 5.56 chambers.
  • PACKAGING: 20 Rounds per carton. 25 cartons per 500 round case.
